RC-C0330 (CCD)

Home Product Center RC-C0330 (CCD)

RC-C0330 (CCD)

Main Feature
-Waterproof: IP68 approved
-Wider viewing angle up to 120
 degrees
-Nightvision distance: approx.
 12 m (18 infrared lights)
-Day/Night sensor for automatic
 adjustment
General details
Sensor 1/3" CMOS (1000TVL)960P
Video ResolutionPAL/NTSC : AHD-M (1200TVL) PAL:1280(H)×960(V)NTSC:1280(H)×960(V)
Minimum iluminationColor: 0.001Lux@(F1.2,AGC ON),0Lux with IR
Black and White:0.001Lux@(F1.2,AGC ON),0Lux with IR
Shutter1/50 (1/60) sec to 1 / 10,000 sec
Lens2.8MM
Day and Nightsupport IR-CUT
Sync systemInter sync
Electronic shutterAuto
White balance modeAuto
Video outputAHD standard output 4-pin aviation cable
IRIR:18PCS LEDS  , 5-15m IR range
S/N>46dB
Power12V dc +/- 10%
Power consumption <5W
Working Temperatura&Humidity -20 ºC ~ 60 ºC, humidity less than 90% (no condensation)
Waterproof IP68
