Convenient use and installation without demolition, wiring ,vehicle refitting, saved the resource of labor force and material,simplified the vehicle modification
| Model | M720DW |
| LCD size | 7" |
| Resolution | 800 x 3 (RGB) x 480 |
| Contrast | 500:01:00 |
| Brightness | 400 cd/m² |
| Viewing Angle | U: 50 / D: 70, R/L: 70 |
| Aspect Ratio | 16:09 |
| Channel | 4 channels |
| Operating Frequency | 2400 - 2483.5 MHz |
| Transmitting Distance | 120 M |
| Recieving Sensitivity | -89 dBm |
| Decompression Form | MPEG4 |
| Emitting Frequency | 17 dBm |
| Modulation | 2.4G FSK/GFSK |
| TF Card | Max. 128G |
| Time Delay | 120ms |
| System Format | PAL / NTSC |
| Power Consumption | Max. 6W |
| Loudspeaker | 1.5W/8 |
| Operating Temperature | -20~+70ºC, RH 90% |
| Storage Temperature | -30~+80ºC, RH 90% |
| Model | C0333DW |
| Image Device | 1/3" CMOS |
| TV System | PAL / NTSC |
| Effective Image Area | 4.6228 mm (H) ×3.6112 mm (V) |
| Sync. System | Internal |
| Resolution | 600 TV Lines |
| Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
| Electronic Exposure | Up to 510:1 |
| S/N Ratio | Better than 48 dB |
| Decompression form | MPEG4 |
| Power Supply | DC 12-32 V |
| Current Consumption | Max. 220 mA/12V |
| Operating frequency | 2400 -2483.5 MHz |
| Transmitting distance | 120M |
| Transmitting speed | 12Mbps |
| Emitting frequency | 17 dBm |
| Lens | f=2.8mm |
| Viewing Angle | 120 degree |
| Waterproof rating | IP69K |
