| Sensor | 1/3" CMOS or CCD sensor | ||||
| Video Resolution | PAL/NTSC 480TVL: 648(H)x488(V) 700TVL: 976(H)×494(V) 720P: 1280(H)×720(V) 1080P 1920(H)×1080(V) | ||||
| Minimum ilumination | Color: 0.1Lux(day),0Lux with IR | ||||
| Lens | 2.8MM/3.6MM | ||||
| Lens angle | 120°/90° | ||||
| Day and Night | support IR-CUT | ||||
| Sync system | Inter sync | ||||
| Electronic shutter | Auto | ||||
| AGC | Auto | ||||
| White balance mode | Auto | ||||
| Video output | 1.0 Vp-p/75 Ohm standard output 4-pin aviation connector other connectors for option | ||||
| IR | 9PCS LEDS , 10m IR range | ||||
| S/N | Better than 48dB | ||||
| Power | 12V dc | ||||
| Current drain | 80±5mA | ||||
| Working Temperatura&Humidity | -20 ºC ~ 70 ºC, RH 95% Max. | ||||
| Waterproof | IP68 | ||||
