| Image Device | 1/3" CMOS | 1/3" CMOS | 1/3'' SHARP CCD |
| TV System | PAL,NTSC | PAL / NTSC | PAL / NTSC |
| Effective Image Area | 4.88 mm x 3.67 mm | 4.6228 mm (H) ×3.6112 mm (V) | - |
| Sync. System | Internal | Internal | Internal |
| Resolution | 800TV Lines | 600 TV Lines | 600 TV Lines |
| Minimum Illumination | 0.01 Lux | 0.1 Lux (day), 0 Lux (with IR) | 0.01 Lux / F1.0, B/W: 0.001 Lux / F1.0 |
| Electronic Exposure | - | Up to 510:1 | Up to 510:1 |
| AGC | Auto | Auto | Auto |
| S/N Ratio | Better than 48dB | Better than 48 dB | Better than 48 dB |
| White Balance | Auto | Auto | Auto |
| BLC | Auto | Auto | Auto |
| Decompression form | MPEG4 | MPEG4 | MPEG4 |
| Power Supply | DC12V | DC 12-32 V | DC 12-32 V |
| Current Consumption | - | Max. 220 mA/12V | Max. 350 mA |
| Operating frequency | 2400-2483.5MHz | 2400 -2483.5 MHz | 2400 -2483.5 MHz |
| Vertical Sync Frequency | 50 Hz/60 Hz | - | - |
| Transmitting distance | 120M | 120M | 120M |
| Transmitting speed | 12Mbps | 12Mbps | 12Mbps |
| Emitting frequency | 17dBM | 17 dBm | 17 dBm |
| Receiving sensitivity | -78dBm | - | - |
| Night vision distance | 5~10m | - | - |
| Lens | f=2.8mm | f=2.8mm | f=2.8mm, 3.6mm |
| Viewing Angle | 120 degree | 120 degree | 120 degree, 92 degree |
| Operating Temperature | -30~85 degree | -20~60 degree, RH 90% MAX. | -20~70 degree, RH 95% MAX. |
| Storage Temperature | -50~95 degree, RH95%MAX. | -30~80 degree, RH 90% MAX. | -40~80 degree, RH 95% MAX. |
| Waterproof rating | IP66 | IP66 | IP66 |
| Microphone | - | Yes | Yes |
| Scan Mode | Progressive | Progressive | - |
| Image mode | mirror/normal (optional) | - | - |
| Video Output | 1.0Vp-p, 75Ohm | - | - |
| Electronic Shutter | - | - | AOTO:1/50-1/100,000 Sec. /1/60-1/100,000 Sec. |
| D-WDR | - | - | ON/OFF |
| 2D-DNR | - | - | ON/OFF |
| Back Light Comp | - | - | ON/OFF |
