RC-MD318A

Home Product Center RC-MD318A

RC-MD318A

Main Feature

-5CH audio input (including 1 channel MIC intercom input);
- Front window display: 128*64 lattice screen;
-Support 3G/4G network; Built-in BD, GPS dual-mode, G-sensor;
- Support 10CH alarm input (2CH analog + 8CH IO alarm input);
- Power supply: support 8V-36V;
- Appearance size: 180mm*60mm*170mm

General details

OS	Linux
Language	Chinese/English/Others (can be customized)
Video Compression	H.264
Video Input	8CH
Video Output	BNC
Display	1/2/4/5/6/8 CH full screen
Signal system	PAL/NTSC (PAL @100Frame, NTSC@120 Frame)
Resolution	1080P/720P/D1/HD1/CIF
Audio Input	5CH, 1CH MIC
Audio Output	3CH
Audio Compression	G711A
Alarm Input	8CH
Alarm Output	2CH
Communication Port	2CH RS232,1CH RS485, Built-in printer
Wireless communications	GPS/3G/4G/WIFI optional
G-Sensor	Support G-Sensor
Storage	Support the built-in maximum 1TB HDD + 2*128GB SD Card
GPS	GPS/GLONASS
Video Search	Search video by Record Time/Record Type etc
Playback	A/V, GPS,Map view,Speed,G-sensor,video files available for playback on PC
CMS	Wireless(require Wi-Fi or cellular), real-time monitoring GPS and alarm etc
Voltage Input	DC:+8V ~ +36V
Voltage Output	+12V @5A
Power off protection	All video information can be saved automatically when the power cut off, and make sure that all the files can not be damaged.
Working Temperature	-30ºC to +70ºC
Humidity	20% to 80%
Size	188mm60mm170mm
Net Weight	1.4kg
