| Image Sensor | 1/2.8" Panasonic CMOS(MN34227PL) |
| Total Pixels | 2000(H) × 1241(V)Approx. 2.48M pixels |
| Scanning System | Progressive |
| Resolution | Digital:1080(30p),720(60p) |
| Min. lllumination | Color:1.0 Lux ,BW: 0.5 Lux , |
| DSS Color:0.017 Lux, BW: 0.0008 Lux | |
| Video Output | CVI:HD-CVI(1080P) |
| Analog:1Vp-p Composite Output(75Ohm/BNC) | |
| S/N Ratio | More than 50Db(AGC off) |
| WDR AEC/DWDR | HD-SDI WDRCVBS DWDR |
| Lens | DC/Manual |
| Brightness | 0-20 |
| 0-20 steps | |
| Sens up | 1x-32x |
| Shutter Speed | AUTO/MANUAL(1/50\60 ~ 1/30,000 sec) |
| Defog | Off/On |
| Shading | Off/On |
| BLC | Off/BLC |
| HLC | Off/HLC |
| Day&Night | Auto/Color/B&W |
| White Balance | Auto/Auto-ext/Preset/Manual |
| MONITOR | 0/1/2/3 |
| DNR (Digit Noise Reduction) | Off/Low/Middle/High |
| Mirror | Off/On |
| H-V-REV | Off/On |
| Sharpness | 0-10steps |
| Digital Zoom | 1.0x-10x |
| Motion | Off/on |
| Language | Chinese/English polyglot |
| Power(Max.) Supply | DC12V ±10%<1.50W |
| Video Output | HD-SDI:SMA connector, CVBS :BNC connector |
| HD-SDI distance | Over 350m distance via Coaxial cables(RG59 75-3 Full Cooper) |
| Working Temperatura&Humidity | -20 ºC ~ 60 ºC, humidity less than 90% (no condensation) |
| Waterproof | IP69K |
