| Technical term | Technical parameters | ||
| Pick-up Device | SONY CCD | SHARP CCD | CMOS(OV7959) |
| Power Supply | 12V dc +/- 10% | ||
| Power consumption | <1W | ||
| Effective pixels | 758*582/728*512 | 128*582/128*512 | 580*540/580*492 |
| S/N Radio | ≥48db | ||
| Resolution | 458(TV Line) | ||
| TV System | PAL/NTSL | ||
| Lens Angle | 120/150 | ||
| Waterproof | IP68 | ||
| White balance mode | AUTO | ||
| AGC | AUTO | ||
| Minimum ilumination | 0.1 lux | 0.3 lux | l lux |
| Electronic shutter | 1/60(NTSC) 1/50(PAL) 1/10,0000second | ||
| Operating Temprature | -20~+75(RH95% MAX) | ||
| Storage Temprature | -30~+80(RH95% MAX) | ||
| Optional fuction | Parking line switch,mirror switch | ||
