7" Digital LCD Monitor RC-M710

Main Feature

-TFT LCD monitor
-Wide view angle & high resolution
-Multi-languages of OSD available
-Video formats: PAL /NTSC/AUTO
-Power supply: 10~32V
-Automatically switches to back-up,
left or right side camera views

General details

Model	M710
LCD size	7"
Resolution	800 x 3 (RGB) x 480 1024 x 3 (RGB) x 600
Contrast	500:1
Brightness	400 cd/m²
Viewing Angle	U: 50° , D: 60° , R/L: 70° /70°
Aspect Ratio	16:09
Channel	3 channels (4 channel optional)
Power Supply	Automobile storage battery (10-32v)
System Format	PAL / NTSC / AUTO
Power Consumption	About 6W
Loudspeaker	1.5W/8Ω
Operating Temperature	-20~+70ºC, RH 90%
Storage Temperature	-30~+80ºC, RH 90%

Accessories:
1- Power cable	1- Center mount bracket
1- U-support bracket	4- Angle adjustment screws
1- IR remote control	1- Manual
