| Image Device | 1/3" CMOS | |
| TV System | PAL / NTSC | |
| Effective Pixels | 728(H)*488(V) | |
| Sensing Area | 4.80 mm (H) ×3.73 mm (V) | |
| Scan Mode | Progressive | |
| Sync. System | Internal | |
| Horizontal Resolution | 700 TV Lines | |
| Minimum Illumination | 0.05 Lux (day), 0 Lux (with IR) | |
| Microphone | Yes | |
| AUTO Electronic Exposure | AUTO | |
| AGC | Auto | |
| S/N Ratio | 46.5dB | |
| White Balance | Auto | |
| BLC | Auto | |
| Current Consumption | Max. 220 mA/12V | |
| Power Supply | DC 12-32 V | |
| Operating frequency | 2400 -2483.5 MHz | |
| Transmitting distance | 30-120M | |
| Transmitting speed | 12Mbps | |
| Decompression form | MPEG4 | |
| Transmit output power | 17 dBm | |
| Lens | f = 2.8mm | |
| Lens Angle | 120° | |
| Operating Temperature | -20°C~60°C, RH 90% MAX. | |
| Storage Temperature | -30°C~80°C, RH 90% MAX. | |
| Accessories: | ||||
| 4- Screws for fixing bracket | 1- 3DB Athena Male | 1- Power supply cable | ||
